Griffith - Chimaera (1991 - 2002)

Name: Griffith - Chimaera (1991 - 2002)
SKU: PF_RS_TVR2
Availability: InStock

SKU

PF_RS_TVR2

Options

Grouped product items
	Amount required per car	Ref. in diagram	Art.no.	Price
Front Upper/Lower Wishbone Front Bush	4	1	PF79-102F	€45.40
Front Upper Wishbone Rear Bush	2	3	PF79-102H	€62.40
Rear Upper Wishbone Front Bush Short	2	4	PF79-101R	€43.91
Rear Upper/Lower Wishbone Bush	10	5	PF79-102R	€43.91
Front Lower Wishbone Rear Bush	2	6	PF79-102S	€56.97
Rear Diff Mounting Front Bush	2	7	PFR79-110	€38.48
Rear Diff Mounting Rear Bush	1	8	PFR79-112	€46.19
Front Anti Roll Bar Bush 22mm	2	10	PFF19-406-22	€29.20
Front Anti Roll Bar Bush 24mm	2	10	PFF19-406-24	€28.48

PF79-102S includes a special stainless steel sleeve to clear the weld spot on the wishbones
PF79-102H includes a heat shield kit as the bush is located near to the exhaust
PFR79-110 does not fit the GKN differential with 41mm front bushes as fitted to vehicles pre-1997.
